Yamaha URX22C Audio Interface

Name: Yamaha URX22C Audio Interface
Brand: Yamaha
SKU: VHX7540
Price: 19800 INR
Availability: InStock

Yamaha URX22C Audio Interface

MRP

₹ 19,800

Inclusive of all taxes

Offers

No Cost EMI Offer Get Up to 12 months No Cost EMI on leading bank cards*

Min. Value ₹4,995 Offer Details

Check Delivery

Highlights

USB Type-C Audio/MIDI Interface with 32-bit integer / 192 kHz support
MIDI input and output
2 D-PRE mic preamps with +48 V phantom power and Mono switch
2 Mic/Line Combo inputs: XLR / 6.3 mm jack - Hi-Z switch on input 2 for electric guitar
2 TRS line outputs, 1 Headphones output
Input mixing channels: 2 mono + 3 stereo loopback + 1 FX
Busses: 1 MIX (Stereo) + 1 FX + 1 STEREO
Three-channel loopback enables flexible streaming and communication setups.
Effects powered by the internal DSP and Basic FX Suite give your sound a professional finish.
Latency-free DSP monitoring with FX for enhanced performance
Sturdy metal housing
Includes Cubase AI for PC, Cubasis LE DAW app for iPhone/iPad, Steinberg Plus and USB cable
USB 3.0 power supply (optional power supply for USB 2.0 required)
Dimensions (W x H x D): 159 x 47 x 159 mm (6.3" x 1.9” x 6.3”)
Net weight: 1.0 kg (2.0 lb)

Description
Technical Specification

You. For Real.

Despite its minimalist footprint, the URX22C packs serious creative power. With professional-grade sound, flexible DSP processing, and a full suite of Steinberg production tools, it gives you everything you need to record, produce, or stream from virtually anywhere - with impressive quality and ease.

Minimum Effort to Maximize Output

The URX22C is an all-in-one interface and software package built for simplicity and results. With Yamaha’s custom DSP and the intuitive dspMixFx app, you can easily balance your mix, add effects, and control your input and output levels - all without deep technical know-how.

Combined with the ultra-compatible Steinberg software bundle, the URX22C makes high-quality recording and streaming simple - freeing you to focus your energy where it matters most: your music and content.

It All Starts With the Sound

With 32-bit/192 kHz audio resolution and Yamaha’s acclaimed D-PRE mic preamps, the URX22C captures every detail with clarity and depth.

Whether you’re recording vocals, instruments, or podcasts, you’ll get the transparent, dynamic sound that professionals rely on — giving you a clear path from inspiration to finished project.

Simple Operation. Serious Functionality.

Designed for fast, intuitive use, the URX22C gives you hands-on control without the clutter. Independent headphones and master volume knobs let you fine-tune your monitoring levels, while the MIX knob blends direct input with playback — perfect for live takes or streaming.

A dedicated MONO button ensures your mix stays balanced across all playback systems, helping you stay confident in what your audience hears.

Everything You Need. Anywhere You Go.

The URX22C comes bundled with powerful tools to elevate your productions. Cubase AI offers a streamlined version of Steinberg’s renowned DAW for multitrack recording and editing, while Steinberg Plus adds inspiring sounds, effects, and virtual instruments.

MixKey simplifies audio routing and streaming, and compatibility with Elgato Stream Deck lets you trigger controls effortlessly. With regular updates and deep integration, your entire setup evolves with your creative journey.

URX22C
General specifications
I/O Connectors	Analog Input	2 Mic/Line Combo inputs *Hi-Z switch on input 2 for electric guitar
	Analog Output	2 TRS
	USB TO HOST	1 (USB Type-C, 32-bit)
	Phones	1 TRS (15 mW+15 mW @40 Ohm)
	DC	2 (Type-C USB bus power or Type-A micro-USB DC IN)
	MIDI	1 IN / 1 OUT
User Interface		Dedicated software "dspMixFx", Input Gain, Mono/Stereo switch, Hi-Z for Input 2, +48V phantom power, Mix balance, Main Volume, Headphones Volume
Recording & Playback	USB	2-track recording, 2-track playback
Sampling frequency rate		192 kHz - 44.1 kHz
Frequency response		+0.0/-0.4 dB (20 Hz to 22 kHz)
Total harmonic distortion		[MIC/LINE/Hi-Z] 0.003 % at 1 kHz, 22 Hz/22 kHz BPF; [MAIN OUTPUT] 0.002 % at 1 kHz, 22 Hz/22 kHz BPF
Dynamic range		[MIC/LINE/Hi-Z] 102 dB, [MAIN OUTPUT] 105 dB
Gain range		54 dB
Power requirements		DC5 V/0.9 A
Power consumption		4.5 W
Dimensions	W	159 mm (6.3")
	H	47 mm (1.9")
	D	159 mm (6.3")
Net weight		1.0 kg (2.0 lb)
Included Accessories		Setup Guide, Cubase AI License Card, Basic FX Suite License Card, Steinberg Plus License Card, USB Cable (3.1 Gen1, Type-C to Type-A, 1.0 m)
Operating temperature		0 to + 40 ℃
Outline
Mixing Capacity	Input Channels	2 Mono + 3 Stereo loopback + 1 FX
	Mix Buses	2 (1 MIX + 1 Streaming Mix)
	Stereo Buses	1
	FX Buses	1
On-board processors	DSP	PitchFix (Voice Changer), Sweet Spot Morphing Channel Strip (Comp & EQ), Guitar Amp Classics (Amp Simulator), Ducker, Compressor, Gate, Multi-Band Compressor, Delay, REV-X (Reverb)

Country of origin: China

Importer Details: Yamaha Music India Pvt. Ltd ; Unit No. 601∼608, 6th Floor, Tower-D,Global Business Park, Sector-26,Mehrauli-Gurgaon Road,Gurugram-122002 Haryana, India
